Vacuum Atmosphere High Temperature Box Furnace Sintering Electric Fuel

Large Image : Vacuum Atmosphere High Temperature Box Furnace Sintering Electric Fuel

Product Details:

Place of Origin:	China
Brand Name:	Chitherm
Model Number:	HBF105-14

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	Customized
Delivery Time:	Customized
Payment Terms:	Customized
Supply Ability:	Customized

Contact Now

Vacuum Atmosphere High Temperature Box Furnace Sintering Electric Fuel

Description

Range Of Applications:	Industrial	Type:	Electric Holding Furnace
Usage:	Steel Molding	Fuel:	Electric
Effective Chamber Dimensions:	400330800mm(WHD)	Setter Plate:	Corundum-Mullite
Transport Package:	Wooden Package	Specification:	8509001200mm (WHD)
Trademark:	Chitherm	Origin:	China
HS Code:	8514101000	Supply Ability:	50 Sets/Year
Customization:	Available	Certification:	ISO
Place Style:	Vertical
Highlight:	Electric Fuel High Temperature Box Furnace , vacuum High Temperature Box Furnace , Sintering vacuum atmosphere furnace

Overview
The HBF105-14 Type Sintering Furnace uses silicon molybdenum rods, which are resistant to acids and alkalis, with good uniformity and simple operation. It is suitable for various laboratories and small-batch production processes.

Main Parameters
Product Model: HBF105-14 Type Sintering Furnace
External Dimensions: 850 * 900 * 1200mm (W×H×D)
Effective Chamber Size: 400 * 330 * 800mm (W×H×D)
Rated Temperature: 1300ºC
Maximum Temperature: 1500ºC
Loading Device: Corundum Mullite Loading Plate
Heating Element: Silicon Molybdenum Rod
Temperature Control Stability: ±1
Chamber Temperature Uniformity: ±5ºC
Number of Temperature Control Segments: 40 segments
Alarm Protection: Interlock between heating and furnace door operation, over-temperature, thermocouple break, and low-pressure audible and visual alarms
Surface Temperature Rise: <35ºC
Number of Temperature Control Points: 1 point
Maximum Heating Power: 23kW
Cooling Method: Natural Cooling with the Furnace
Heating Rate: ≤10ºC/min
Equipment Weight: 500Kg
Installation Dimensions: 800 * 900 * 1200mm (D×W×H)
Power Supply: Capacity greater than 30kVA, three-phase five-wire 220/380V, 50Hz

The Hbf105-14 Type Sintering Furnace Is a Muffle Furnace Used for High-Temperature Processing.

Item	pecifications	Quantity	Notes
Kiln Main Unit	Primary heating system	1 set	Core equipment for thermal process
Setter Plate	Material: Corundum-Mullite	1 set	High-temperature resistant carrier

Installation and Usage Conditions

The equipment must be installed indoors, with an ambient temperature of -10ºC to 45ºC. The indoor environment should be free of flammable gases, corrosive gases, and steam.
The equipment requires a floor area of no less than 4 square meters, with a working space length of no less than 2 meters, width of no less than 2 meters, and height of no less than 3 meters. The foundation should be sturdy and level, with the furnace weighing approximately 400kg.
The power supply for this furnace must be a three-phase five-wire AC power line, 380±10%V, 50±2%Hz. This power line should be dedicated, and large power conversion equipment such as welding machines, electric furnaces, and metal cutting machines should not be connected to this distribution.
The equipment must be reliably grounded.
