Bf580-17 High Temperature Bell Jar Furnace For Air And O2 Atmosphere

Large Image : Bf580-17 High Temperature Bell Jar Furnace For Air And O2 Atmosphere

Product Details:

Place of Origin:	China
Brand Name:	Chitherm
Model Number:	Bf580-17

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	100000
Delivery Time:	90 work days
Payment Terms:	L/C,T/T
Supply Ability:	50 Sets/Year

Contact Now

Bf580-17 High Temperature Bell Jar Furnace For Air And O2 Atmosphere

Description

Range Of Applications:	Industrial	Type:	Electric Holding Furnace
Usage:	Ceramic Sintering	Fuel:	Electric
Atmosphere:	Air And O2	Effective Chamber Dimensions:	1200600800mm(DWH)
Warranty:	1 Year	Temperature Range:	1700ºC-1750ºC
Transport Package:	Wooden Packaging
Highlight:	Bf580-17 Bell Jar Furnace , High Temperature Bell Jar Furnace

BF580-17 High-Temperature Bell Jar Furnace

Product Overview

Industrial-grade electric bell jar furnace designed for high-temperature ceramic sintering applications, featuring precise temperature control up to 1750ºC.

Key Specifications

Attribute	Value
Application Range	Industrial
Furnace Type	Electric Holding Furnace
Primary Usage	Ceramic Sintering
Atmosphere	Air and O₂
Chamber Dimensions	1200×600×800mm (D×W×H)
Temperature Range	1700ºC-1750ºC
Warranty	1 Year

Applications

This high-temperature furnace is engineered for sintering processes in advanced ceramics, magnetic materials, and electronic ceramic components manufacturing.

Technical Specifications

Effective Chamber Size: 1200×600×800mm (D×H×W)
External Dimensions: 2880×3600×2240mm (excluding tracks and control cabinet)
Temperature Range: 1700ºC~1750ºC
Heating Method: Silicon molybdenum rod heating elements
Insulation: Alumina products/ceramic fiber material
Control System: Imported Japanese intelligent temperature controller
Power Requirements: 220/380VAC 50Hz, 120kW max power
Equipment Weight: Approximately 8000kg

Standard Delivery Contents

Item	Description	Quantity
Basic Components	Furnace assembly	1 SET
Certificates	Component inspection certificates	1 SET
Technical Documents	Operation manuals and technical specifications	1 SET
Heating Elements	U-shaped silicon molybdenum heaters	1 SET
Control System	Temperature controller, PLC, and touch screen	1 SET
Spare Parts	Additional heating element	1 PC

Operating Requirements

Environment: 0-40ºC, ≤80% humidity, no corrosive gases
Atmosphere: Dry, clean compressed air (0.4-0.8MPa)
Ventilation: Exhaust system with >50 m³/h capacity
Floor Load: >1000 Kg/m², vibration-free
Power: >160kVA, 3-phase 380V supply
Space Requirements: Minimum 6×4×4m installation area

Frequently Asked Questions

What products does Chitherm offer?

We specialize in high-temperature industrial furnaces including bell furnaces, vacuum furnaces, tube furnaces, rotary kilns, and customized thermal processing solutions.

What pre-sales services are available?

Our technical team provides comprehensive consultation services and custom engineering solutions to match your specific process requirements.

What are Chitherm's core strengths?

As an integrated R&D and manufacturing enterprise, we combine patented technologies with extensive industry experience to deliver reliable, high-performance thermal processing equipment.
