Chitherm Mbf40-11n 1100c Intelligent Nitrogen Box Furnace

Name: Chitherm Mbf40-11n 1100c Intelligent Nitrogen Box Furnace
Brand: Hefei Chitherm Equipment Co., Ltd
SKU: MBF40-10N
Availability: InStock

All Products

High Temperature Box Furnace
(109)

Elevator Furnace
(72)

Hot Air Drying Oven
(56)

Atmosphere Box Furnace
(34)

Vacuum Muffle Furnace
(56)

Tube Furnace
(10)

Rotary Furnace
(4)

Waste Gas Incinerator
(4)

Continuous Annealing Furnace
(3)

Electric Muffle Furnace
(11)

Debinding Furnace
(1)

Conveyor Belt Furnace
(8)

Furnace Parts
(2)

Customer Reviews

Dear Valued Partner, Thank you for your support and trust over the past year. It is through your cooperation that we have been able to successfully achieve our goals. In the days to come, we look forward to continuing our close collaboration and creating even greater value together. — With best regards, [Chinese Academy of Sciences]

—— Chinese Academy of Sciences

I'm Online Chat Now

Chitherm Mbf40-11n 1100c Intelligent Nitrogen Box Furnace

Large Image : Chitherm Mbf40-11n 1100c Intelligent Nitrogen Box Furnace

Product Details:

Place of Origin:	China
Brand Name:	Chitherm
Model Number:	MBF40-10N

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	Customized
Delivery Time:	Customized
Payment Terms:	Customized
Supply Ability:	Customized

Contact Now Chat Now

Chitherm Mbf40-11n 1100c Intelligent Nitrogen Box Furnace

Description

Range Of Applications:	Industrial	Type:	Electric Holding Furnace
Usage:	Ceramic Sintering	Fuel:	Electric
Atmosphere:	Air	Effective Chamber Dimensions:	330200660mm(WHD)
Transport Package:	Wooden Packaging	Specification:	115019701460mm(WHD)
Trademark:	Chitherm	Origin:	China
HS Code:	8514101000	Supply Ability:	50 Sets/Year
Customization:	Available	Certification:	ISO
Place Style:	Vertical
Highlight:	1100C nitrogen box furnace , intelligent high temperature furnace , Mbf40-11n box furnace with warranty

Chitherm MBF40-11N 1100°C Intelligent Nitrogen Box Furnace

Product Specifications

Attribute	Value
Range of Applications	Industrial
Type	Electric Holding Furnace
Usage	Ceramic Sintering
Fuel	Electric
Atmosphere	Air
Effective Chamber Dimensions	330200660mm (WHD)
Transport Package	Wooden Packaging
Specification	115019701460mm (WHD)
Trademark	Chitherm
Origin	China
HS Code	8514101000
Supply Ability	50 Sets/Year
Customization	Available
Certification	ISO
Place Style	Vertical

Product Description

The MBF40-10N industrial box furnace is designed for ceramic sintering applications with temperature ranges from 850-1000°C, featuring advanced atmosphere control and uniform heating technology.

Key Features

Silicon carbide heating elements resistant to acid/alkali corrosion
Dual heating element arrangement for uniform temperature distribution
Alumina inner chamber with ceramic fiber outer insulation
Precision temperature control with ±5°C uniformity
Comprehensive safety alarms and protection systems

Technical Parameters

Model: MBF40-10N Atmosphere Box Furnace
Rated Temperature: 850-1000°C
Effective Dimensions: 330×200×660mm (W×H×D)
Heating Power: ≤25kW
Power Supply: Three-phase, 220/380V, 50Hz
Temperature Control: 20 program steps, two-point control

Key Components

Furnace frame and chamber
Ceramic tube-encased silicon carbide heating elements
Azbil temperature controller with touch screen
Safety chimney and door interlock system

Delivery Contents

Item	Description	Quantity
Basic Furnace	Complete furnace assembly	1 PC
Certificates	Inspection documents	1 Set
Technical Documents	Specifications and manuals	1 Set
Heating Elements	Silicon carbide rods	1 Set
Temperature Controller	Azbil system	1 Set
Touch Screen	Control interface	1 Set
Spare Parts	Silicon carbide rod	1 PC

Installation Requirements

Environment: 0-40°C, ≤80% RH, no corrosive gases
Process gas: 99.999% nitrogen at 0.2-0.4Mpa
Ventilation: Minimum 15m³/h capacity
Power: 35kVA, 3-phase 220/380V, 50Hz
Space: Minimum 2500×2000×3000mm (W×H×D)

Certifications

Packaging & Shipping

About Chitherm

Hefei Chitherm Equipment Co., Ltd. specializes in the R&D and manufacturing of high-quality industrial and laboratory furnaces for applications in advanced ceramics, electronics, powder metallurgy, and new energy sectors. Our product range includes bell furnaces, box furnaces, vacuum furnaces, and specialized kilns for material processing.

Our Capabilities

Custom furnace solutions for specialized applications
ISO certified manufacturing processes
Comprehensive technical support and service
Patented technologies in thermal processing
