Industrial Electric Clean Hot Air Oven Drying 200 Ordm C 220V 50Hz

Electric Clean Drying Oven with 200 ordm C Temperature and 600*500*600mm Effective Chamber Dimensions

Technical Specifications:

1. Equipment Model: SZC-180 Type Clean Drying Oven
2. Maximum Temperature: 200°C, Operating Temperature: 85 - 150°C
3. Oven Dimensions: 900mm × 650mm × 1150 mm (L × W × H)
4. Chamber Dimensions: 600mm × 500mm × 600mm (L × W × H)
5. Design Power: 4 kW
6. Insulation Power: 2 kW
7. Electrical Supply: 220V, 50Hz
8. Heating Element: High-quality heating wire, lightweight fiber material with low thermal capacity, excellent insulation properties, fast heating, energy-saving, time-saving, and easy environmental temperature control.
9. Insulation Material: Aluminum Silicate Fiber Blanket
10. Control Method: Imported single-loop intelligent temperature controller with PID control, auto-tuning of parameters.
11. Number of Temperature Control Zones: 1
12. Alarm Protection: Over-temperature, circulating fan failure, etc., with audio-visual alarm protection and automatic power cutoff. After a high-temperature alarm cuts off the power, the heating power can only be manually restored when the temperature drops to the normal operating range before restarting.
13. Temperature Control Accuracy: ±1°C
14. Temperature Uniformity: ≤±2°C
15. Fan Power: 1/4 HP motor, high-temperature resistant, low noise
16. Insulation Protection: Independently processed extended shaft core for the fan
17. Impeller Structure: Multi-blade design
18. Airflow Channel Design: Unique design with porous stainless steel walls, ensuring no dead spots in circulation.
