Hwf6630-10 Type Tank Type Gas Phase Deposition Furnace For Experimental Purposes

Hwf6630-10 Type Tank Type Gas Phase Deposition Furnace For Experimental Purposes
Hwf6630-10 Type Tank Type Gas Phase Deposition Furnace For Experimental Purposes
Hwf6630-10 Type Tank Type Gas Phase Deposition Furnace For Experimental Purposes Hwf6630-10 Type Tank Type Gas Phase Deposition Furnace For Experimental Purposes Hwf6630-10 Type Tank Type Gas Phase Deposition Furnace For Experimental Purposes Hwf6630-10 Type Tank Type Gas Phase Deposition Furnace For Experimental Purposes Hwf6630-10 Type Tank Type Gas Phase Deposition Furnace For Experimental Purposes Hwf6630-10 Type Tank Type Gas Phase Deposition Furnace For Experimental Purposes Hwf6630-10 Type Tank Type Gas Phase Deposition Furnace For Experimental Purposes Hwf6630-10 Type Tank Type Gas Phase Deposition Furnace For Experimental Purposes Hwf6630-10 Type Tank Type Gas Phase Deposition Furnace For Experimental Purposes

Large Image :  Hwf6630-10 Type Tank Type Gas Phase Deposition Furnace For Experimental Purposes

Product Details:
Place of Origin: China
Brand Name: Chitherm
Model Number: Hwf6630-10
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 23450.26-27917
Delivery Time: 90 work days
Payment Terms: L/C,T/T
Supply Ability: 50 Sets/Year
Contact Now

Hwf6630-10 Type Tank Type Gas Phase Deposition Furnace For Experimental Purposes

Description
Heating Zone Dimensions: Φ660×300mm(D*H) Heating Rate: ≤6ºC/Min
Usage: Ceramic Sintering Range Of Applications: Industrial
Temperature Control Stability: ±1ºC Atmosphere: Nitrogen/Hydrogen/Acetylene
Package Gross Weight: 750.000kg
Highlight:

Experimental Purposes Gas Phase Deposition Furnace

,

Tank Type Gas Phase Deposition Furnace

HWF6630-10 Type Tank-Type Gas Phase Deposition Furnace for Experimental Purposes
Product Specifications
Attribute Value
Heating Zone Dimensions Φ660×300mm(D*H)
Heating Rate ≤6ºC/Min
Usage Ceramic Sintering
Range of Applications Industrial
Temperature Control Stability ±1ºC
Atmosphere Nitrogen/Hydrogen/Acetylene
Package Gross Weight 750.000kg
Product Overview

The HWF6630-10 tank vapor deposition furnace is designed for medium-temperature heat treatment of electronic products. It supports vapor phase reaction processes in nitrogen, acetylene, and hydrogen atmospheres, as well as sintering processes under protective atmospheres. Equipped with a real-time computer monitoring system, this furnace is ideal for material process testing in research environments.

Hwf6630-10 Type Tank Type Gas Phase Deposition Furnace For Experimental Purposes 0
Technical Parameters
  • Model: HWF6630-10
  • Operating Temperature: 750°C
  • Maximum Temperature: 1000°C
  • Effective Chamber Size: Φ600×300mm (D×H)
  • Heating Element: Internal heating with stainless steel heating tubes
  • Processing Atmosphere: Nitrogen, Hydrogen, Acetylene
  • Heating Method: FEC ceramic fiber heater
  • Temperature Control Points: 2
  • Temperature Stability: ±1°C, with PID parameter self-tuning function
  • Control Method: Touch screen + PLC centralized control
  • Alarm Protection: Audible and visual alarms for overtemperature and thermocouple breakage
  • Heating Rate: ≤6°C/min
  • Heating Power: 16kW
  • Power Requirements: 3-phase 5-wire, 220/380V, 50Hz
  • External Dimensions: 1185×1745×1780mm (W×H×D)
Standard Delivery Package
Item Note Quantity
Basic Components Furnace 1 UNIT
Inspection Certificate Certificate of major outsourced components 1 SET
Control Cabinet 1 UNIT
Technical Documents Instructions and technical documents 1 SET
Temperature Control Module Yamatake or similar imported brand 1 SET
Touchscreen 10 inches 1 SET
Mass Flow Meter Nitrogen 200L/min, others 50L/min 3 PCS
FEC Heater Ceramic fiber embedded with spiral resistance wire 1 SET
Furnace Liner SUS310S 1 PCS
Spare Parts SSR and sealing strip 1 PCS each
Installation Requirements
  • Environmental Conditions: Temperature 0~40°C, humidity ≤80% RH, no corrosive gases
  • Floor Requirements: Level, no significant vibration, load-bearing capacity >500 kg/m²
  • Power Requirements: Capacity >22 kVA, 3-phase 5-wire, 220/380V, 50Hz
  • Installation Space: 1500 mm × 1500 mm × 3000 mm (D × W × H)
Hwf6630-10 Type Tank Type Gas Phase Deposition Furnace For Experimental Purposes 1 Hwf6630-10 Type Tank Type Gas Phase Deposition Furnace For Experimental Purposes 2 Hwf6630-10 Type Tank Type Gas Phase Deposition Furnace For Experimental Purposes 3
Frequently Asked Questions
What products does Chitherm offer?

We provide high-quality bell furnaces, hot air furnaces, box furnaces, tube furnaces, vacuum furnaces, car bottom furnaces, rotary kilns, mesh belt furnaces, and pusher furnaces.

What pre-sales services does Chitherm provide?

We offer consultation services to help customers select suitable products and provide customizable solutions to meet specific requirements.

What are Chitherm's core strengths?

As a high-tech enterprise, we possess patented technologies and core resources to deliver superior furnace solutions for various industrial applications.

About Hefei Chitherm Equipment Co., Ltd.

We specialize in the research, development, and manufacturing of high-, medium-, and low-temperature industrial furnaces and laboratory furnaces. Our product range includes bell furnaces, box furnaces, hot air furnaces, vacuum furnaces, tube furnaces, mesh belt furnaces, and more, serving industries such as advanced ceramics, electronic components, powder metallurgy, new energy, and photovoltaics.
